| B/F系列產品 | |||||||
| 1 法國品牌，軍工品質 France brand,military quality 3 先進的機組安保系統 Advancde gen-sets security system 5 適合多種應用場景的結構/功能解決方案 Professional structure/function solution for varieties of scenarios | 2 行業先進的產品性能指標 Excellent product performance indicators leading industry 4 專業的發電機組應用集成能力 Professional application & integration capabilities for gen-sets 6 具備國內各類產品認證資質以及CE認證 Have kinds of domestic product certification and CE certification | ||||||
| 機組型號 Gensets Model | WPG825B7 | WPG880B7 | WPG900B7 | WPG990B7 | WPG1000B7 | WPG1100B7 | WPG1125B7 |
| 額定功率/容量(kW/kVA) Rated Power/Capacity | 600/750 | 640/800 | / | 720/900 | / | 800/1000 | / |
| 備用功率/容量(kW/kVA) Standby Power/Capacity | 660/825 | 704/880 | 720/900 | 792/990 | 800/1000 | 880/1100 | 900/1125 |
| 發動機型號Engine Model | 12M26D748E200 | 12M26D792E200 | 12M26D792E200 | 12M26D902E200 | 12M26D902E200 | 12M26D968E200 | 12M26D968E200 |
| 額定功率(kW)Rated Power | 680 | 720 | 720 | 820 | 820 | 880 | 880 |
| 備用功率（kW）Standby Power | 748 | 792 | 792 | 902 | 902 | 968 | 968 |
| 氣缸數-缸徑×行程 Cylinder No.-Bore×Stroke | 12-150X150 | ||||||
| 排量（L）Displacement | 31.8 | ||||||
| 啟動方式 Starting Method | DC24V電啟動 Electrical Starting | ||||||
| 調速方式Speed Governor | 電子調速/電控 Electronic/ECU | ||||||
| 進氣方式Intake Way | 增壓中冷 Turbo & Inter-cooling | ||||||
| 機油容量(L)Oil Capacity | 113 | ||||||
| 冷卻液容量（L） Coolant Capacity | 198 | ||||||
| 經濟燃油消耗率(g/kW.h) Economic Fuel Consumption | 196 | ||||||
| 額定電壓（V） Rated Voltage | 400/230 | ||||||
| 頻率(Hz)Frequency | 50 | ||||||
| 額定電流(A) Rated Current | 1083 | 1155 | 1299 | 1299 | 1443 | 1443 | 1624 |
| 額定功率因數 Rated Factor | 0.8（滯后lag） | ||||||
| 相數及接法 Phase No.& Connection | 三相四線，星型接法 3P4W,Y Style Connection | ||||||
| 調壓方式 Voltage Regulation Mode | 自動調壓AVR | ||||||
