| B/F系列產品 | |||||||
| 1 源自歐洲技術，自主研發 Original European technology，independent R&D 3 高可靠性，低排放、低噪音 High reliability,low emissions,low noise 5 適合多種應用場景的結構/功能解決方案 Professional structure/function solution for varieties of scenarios | 2 行業先進的產品性能指標 Excellent product performance indicators leading industry 4 專業的發電機組應用集成能力 Professional application & integration capabilities for gen-sts 6 具備國內各類產品認證資質以及CE認證 Have kinds of domestic product certification and CE certification | ||||||
| 機組型號Gensets Model | WPG55B9 | WPG68.5B9 | WPG88B9 | WPG110B9 | WPG123.5B9 | WPG137.5B9 | WPG165B9 |
| 額定功率/容量(kW/kVA) Rated Power/Capacity | 40/50 | 50/62.5 | 64/80 | 80/100 | 90/112.5 | 100/125 | 120/150 |
| 備用功率/容量(kW/kVA) Standby Power/Capacity | 44/55 | 55/68.5 | 70.4/88 | 88/110 | 99/123.5 | 110/137.5 | 132/165 |
| 發動機型號Engine Model | WP4D66E200 | WP4D66E200 | WP4D100E200 | WP4D100E200 | WP6D132E200 | WP6D132E200 | WP6D152E200 |
| 額定功率(kW)Rated Power | 60 | 60 | 90 | 90 | 120 | 120 | 138 |
| 備用功率（kW）Standby Power | 66 | 66 | 100 | 100 | 132 | 132 | 152 |
| 氣缸數-缸徑×行程 Cylinder No.-Bore×Stroke | 4-105X130 | 6-105X130 | |||||
| 排量（L）Displacement | 4.5 | 6.75 | |||||
| 啟動方式Starting Method | DC24V電啟動 Electrical Starting | ||||||
| 調速方式Speed Governor | 機械調速/電子調速 Mechanical/Electronic | 電子調速 Electronic | |||||
| 進氣方式Intake Way | 渦輪增壓Turbocharged | 增壓中冷 Turbo & Inter-cooling | |||||
| 機油容量(L)Oil Capacity | 10 | 18 | |||||
| 冷卻液容量（L） Coolant Capacity | 18 | 28 | |||||
| 經濟燃油消耗率(g/kW.h) Economic Fuel Consumption | 205 | 200 | |||||
| 額定電壓（V） Rated Voltage | 400/230 | ||||||
| 頻率(Hz)Frequency | 50 | ||||||
| 額定電流(A)Rated Current | 72 | 90 | 115 | 144 | 162 | 181 | 217 |
| 額定功率因數Rated Factor | 0.8（滯后lag） | ||||||
| 相數及接法 Phase No.& Connection | 三相四線，星型接法 3P4W,Y Style Connection | ||||||
| 調壓方式 Voltage Regulation Mode | 自動調壓AVR | ||||||
