| B/F系列產品 | ||||||
| 1 源自歐洲技術，自主研發 Original European technology，independent R&D 3 全球第一銷量發動機動力 The world's first sales engine power 5 適合多種應用場景的結構/功能解決方案 Professional structure/function solution for varieties of scenarios | 2 行業先進的產品性能指標 Excellent product performance indicators leading industry 4 專業的發電機組應用集成能力 Professional application & integration capabilities for gen-sts 6 具備國內各類產品認證資質以及CE認證 Have kinds of domestic product certification and CE certification | |||||
| 機組型號Gensets Model | WPG206B8 | WPG247.5B8 | WPG250B8 | WPG275B8 | WPG344B8 | WPG375B8 |
| 額定功率/容量(kW/kVA) Rated Power/Capacity | 150/187.5 | 180/225 | / | 220/250 | 250/312.5 | / |
| 備用功率/容量(kW/kVA) Standby Power/Capacity | 165/206 | 198/247.5 | 200/250 | 220/275 | 275/344 | 300/375 |
| 發動機型號Engine Model | WP10D200E200 | WP10D238E200 | WP10D238E200 | WP10D264E200 | WP10D320E200 | WP10D320E200 |
| 額定功率(kW)Rated Power | 182 | 216 | 216 | 240 | / | / |
| 備用功率（kW）Standby Power | 200 | 238 | 238 | 264 | 320 | 320 |
| 氣缸數-缸徑×行程 Cylinder No.-Bore×Stroke | 6-126X130 | |||||
| 排量（L）Displacement | 9.726 | |||||
| 啟動方式Starting Method | DC24V電啟動 Electrical Starting | |||||
| 調速方式Speed Governor | 電子調速 Electronic | |||||
| 進氣方式Intake Way | 增壓中冷 Turbo & Inter-cooling | |||||
| 機油容量(L)Oil Capacity | 23 | |||||
| 冷卻液容量（L）Coolant Capacity | 51 | |||||
| 經濟燃油消耗率(g/kW.h)Economic Fuel Consumption | 198 | |||||
| 額定電壓（V）Rated Voltage | 400/230 | |||||
| 頻率(Hz)Frequency | 50 | |||||
| 額定電流(A)Rated Current | 271 | 324 | 361 | 361 | 451 | 541 |
| 額定功率因數Rated Factor | 0.8（滯后lag） | |||||
| 相數及接法 Phase No.& Connection | 三相四線，星型接法 3P4W,Y Style Connection | |||||
| 調壓方式 Voltage Regulation Mode | 自動調壓AVR | |||||
