| B系列產品 | ||||||
| 1 源自濰柴60多年自主研發技術的全新產品 Weichai new generation based on more than 60 years'sD&R experience and technology 3 動力強勁、可靠性高 Strong power,high reliability 5 專業的發電機組應用集成能力 Professional application & integration capabilities for gen-sets | 2 行業先進的產品性能指標 Excellent product performance indicators leading industry 4 性價比高，超長維保周期 High cost performance,long maintenance cycle 6 適合多種應用場景的結構/功能解決方案 Professional structure/function solution for varieties of scenarios | |||||
| 機組型號Gensets Model | WPG550B5 | WPG575B5 | WPG687.5B5 | WPG700B5 | ||
| 額定功率/容量(kW/kVA) Rated Power/Capacity | 400/500 | / | 500/625 | / | ||
| 備用功率/容量(kW/kVA) Standby Power/Capacity | 440/550 | 460/575 | 550/687.5 | 560/700 | ||
| 發動機型號Engine Model | WHM6160D518-5 | WHM6160D518-5 | WHM6160MD628-5 | WHM6160MD628-5 | ||
| 額定功率(kW)Rated Power | 471 | / | 571 | / | ||
| 備用功率（kW）Standby Power | 518 | 518 | 628 | 628 | ||
| 氣缸數-缸徑×行程 Cylinder No.-Bore×Stroke | 6-160X200 | 6-160X216 | ||||
| 排量（L）Displacement | 24.12 | 26.04 | ||||
| 啟動方式Starting Method | DC24V電啟動 Electrical Starting | |||||
| 調速方式Speed Governor | 電子調速 Electronic | |||||
| 進氣方式Intake Way | 增壓中冷 Turbo & Inter-cooling | |||||
| 機油容量(L)Oil Capacity | 55 | 55 | ||||
| 冷卻液容量（L）Coolant Capacity | 130 | 140 | ||||
| 經濟燃油消耗率(g/kW.h)Economic Fuel Consumption | 198 | |||||
| 額定電壓（V）Rated Voltage | 400/230 | |||||
| 頻率(Hz)Frequency | 50 | |||||
| 額定電流(A)Rated Current | 722 | 830 | 902 | 1010 | ||
| 額定功率因數Rated Factor | 0.8（滯后lag） | |||||
| 相數及接法 Phase No.& Connection | 三相四線，星型接法 3P4W,Y Style Connection | |||||
| 調壓方式Voltage Regulation Mode | 自動調壓AVR | |||||
